STPD STS S5M-425 Arc Tooth Industrial Rubber Engine Timing Synchronous Conveyor Belt
Arc Tooth Timing Belt is a transmission belt used to transmit power and motion. It has a special tooth profile consisting of a series of arc-shaped teeth that match the teeth of a transmission, usually a gear.
Compared with the traditional straight tooth timing belt, the main advantage of the arc tooth timing belt is that it reduces the impact and noise between teeth and provides smoother transmission. This is because the contact between the teeth of the arc tooth timing belt and the gear teeth is gradually established and released, rather than sudden contact and separation.
Structure:
1. Back & Tooth Rubber: High quality Neoprene,provides protection against oil,grease,heat and aging.
2. Fiberglass Tension Layer: Glass fiber cord,provides high strength,good flexing performance and elongation
3. Tooth Surface: nylon canvas,Nylon fabric,provides resistance to abrsion and tooth shear
Technical parameters:
|
Tooth Profile |
Type |
Pitch(mm) |
Tooth Height(mm) |
Belt Thickness(mm) |
|
HTD |
2M |
2.00 |
0.75 |
1.36 |
|
3M |
3.00 |
1.17 |
2.4 |
|
|
5M |
5.00 |
2.06 |
3.8 |
|
|
8M |
8.00 |
3.36 |
6.00 |
|
|
14M |
14.00 |
6.02 |
10.00 |
|
|
20M |
20.00 |
8.4 |
13.20 |
|
|
STPD/STS |
S2M |
2.00 |
0.76 |
1.36 |
|
S3M |
3.00 |
1.14 |
1.9 |
|
|
S4.5M |
4.50 |
1.71 |
2.81 |
|
|
S5M |
5.00 |
1.91 |
3.4 |
|
|
S8M |
8.00 |
3.05 |
5.3 |
|
|
S14M |
14.00 |
5.3 |
10.2 |
|
|
RPP/HPPD |
P2M |
2.00 |
0.76 |
1.36 |
|
P3M |
3.00 |
1.15 |
1.9 |
|
|
P5M |
5.00 |
1.95 |
3.5 |
|
|
P8M |
8.00 |
3.2 |
5.5 |
|
|
P14M |
14.00 |
6.00 |
10 |
Advantage:
Good anti-crack performance, not easy to deform.
Ozone-resistant, wear-resistant and heat-resistant.
Good anti-aging properties and corrosion resistance.
Application:
Food, automobile, textile, pharmaceutical, printing, paper and other industries.
