Product Details:
Payment & Shipping Terms:
|
| Material: | ALLOY STEEL | Advantage: | Wear Resistant, Sharp |
|---|---|---|---|
| Type: | Rolling Pelletizer Knife | Application: | Granulator Machinery Blades |
| Highlight: | Rotary Pelletizer Blades,Granulator Machine Pelletizer Blades,Waste Plastic Recycling Pelletizer Blades |
||
| Material | Tungsten steel,S45C,SKD11,9CrSi,Customizable | ||||
| Keyword | Granulator Knife | ||||
| Flatness, thickness tolerance | 0.003mm | ||||
| Hardness | 58-60HRA, Customizable | ||||
| Palallelism | <0.1 or 0.002mm | ||||
| Surface roughness | Ra0.2 | ||||
| Thickness tolerance | ±0.025mm | ||||
| Four tempering, manual grinding | Production requirement | ||||
| certificate | SGS tested | ||||
| Service | Can be returned and exchanged within 90 days | ||||
| Specification | Outer diameter | Inside diameter | Length | Cutter tooth number | Material |
| Φ100*Φ50*100 | Φ100 | Φ50 | 100 | 14 |
Tungsten steel + (S45C) |
| Φ140*Φ40*140 | Φ140 | Φ40 | 140 | 18 | |
| Φ160*Φ50*160 | Φ160 | Φ50 | 160 | 22 | |
| Φ180*Φ100*180 | Φ180 | Φ100 | 180 | 26 | |
| Φ200*Φ130*200 | Φ200 | Φ130 | 200 | 32 | |
| Size | Can be customized according to customer requirements | ||||
|
Technology : impact resistance, wear resistance, high temperature resistance. The pelletizer blade is suitable for : pelletizing most plastic particles such as PE, PP, PVC, PS, ABS, AS and HIPS. |
|||||
Rotary Pelletizer Knife Application:
